Calculix_2.23_4win.zip need a password

1

just a feedback on the calculix_2.23_4win.zip zipped file (probably an oversight)

2

Thanks for the info. We replace the file soon.

1 Like
3

Nice, it’s fixed now

4

Uhhh. Great!!. Thank very much Don Guido and congratulations for this new release.

Regards

1 Like
5

ÂżHas someone else notice a substantial increment in the time required for complete the analysis?

Same file, same number of cores,.. I’m comparing differences between version 2.22 and 2.23 in case there is some point that could be set up different in my computer. ¿Maybe a new system variable required?. I would appreciate any advice.

imagen
imagen463×788 18.5 KB

1 Like
6

Looking at the screenshot, the windows executable is built with PastiX 6.4.0.

How was this done?

Looking at the diff between 2.22 and 2.23, there does not seem to be a lot of change in pastix.c.

The README.INSTALL file still mentions GitHub - Dhondtguido/PaStiX4CalculiX, which hasn’t been changed in four years and which uses a modified version of PastiX 6.0.1.

7

Look here:

2 Likes
8

This has not been merged and is not part of 2.23, as far as I can tell…

1 Like
9

Using my scripts (with some updates that I will push shortly) I can build ccx 2.23 with PaStiX4CalculiX as modified by Kabbone to work without CUDA (PaStiX4CalculiX-2.17_cudaless).

Given that the work done by Kabbone to make CalculiX work with PaStiX 6.4 has not been merged yet, the executable that Disla used (which I presume came from Calculix_2.23_4win.zip) is probably a modification of 2.23.

2 Likes
10

With an executable built from the 2.23 source (using PaStiX4CalculiX-2.17_cudaless), I don’t see a significant difference in CalculiX time compared to an executable built from the 2.22 source using the same method.

1 Like
11

I’m using the last calculix_2.23_4win.zip downloaded from the official calculix webside. Uncompress and executed without any modification. 2.22 was also the oficial from calculix_2.22_4win.zip. Both versions are the ccx_dynamic.exe.

12

In my case, Calculix_2.23_4win.zip is twice slower than ccx2.22PaStiX.

13

same with pardiso/spooles? which OS, windows 10 or 11?

14

Mine is Win10. Pardiso doesn’t seems affected ( it’s slightly faster than Pastix 2.22).

I never use spooles. I have tried again just for curiosity but it’s not comparable

15

in my case, on windows 11.

16

The change in run time for this specific executable is clearly due to newer PaStiX version 6.4.0 being used, which does not include performance enhancements from PaStiX4CalciliX. Also I wouldn‘t call this a 2.23 build since it obviously includes sources from an unmerged pull request.

1 Like
